Single-Bonded Functional Groups
When you cut yourself, it is often a good idea to swab the cut with rubbing alcohol to disinfect it. Most rubbing alcohols that are sold in drugstores are based on 2-propanol (common name: isopropanol), C3H8O. You can also swab a cut with a rubbing alcohol based on ethanol, C2H6O. Often it is hard to tell the difference between these two compounds. Both have a sharp smell, and both evaporate quickly. Both are effective at killing bacteria and disinfecting wounds. What is the connection between these compounds? Why is their behaviour so similar?
Functional Groups
Both 2-propanol and ethanol contain the same functional group, an OH (hydroxyl) group, as shown in Figure 1.12. Because ethanol and 2-propanol have the same OH functional group, their behaviour is similar.
The general formula for a family of simple organic compounds is R + functional group. The letter R stands for any alkyl group. (If more than one alkyl group is present, R′ and R′′ are also used.) For example, the general formula ROH refers to any of the following compounds: CH3OH, CH3CH2OH, CH3CH2CH2OH, CH3CH2CH2CH2OH, etc.
Organic compounds are named according to their functional group. Generally, the suffix of a compound’s name indicates the most important functional group in the molecule. For example, the suffix -ene indicates
the presence of a double bond, and the suffix -ol indicates the presence of a hydroxyl group.
Functional groups are a useful way to classify organic compounds, for two reasons: 1. Compounds with the same functional group often have similar physical properties. In the next two sections, you will learn to recognize various functional groups. You will use functional groups to help you predict the physical properties of compounds.
2. Compounds with the same functional group react chemically in very similar ways. In Chapter 2, you will learn how compounds with each functional group react.
Table 1.4, on the next page, lists some of the most common functional groups.
Physical Properties and Forces Between Molecules
Organic compounds that have the same functional group often have similar physical properties, such as boiling points, melting points, and solubilities. Physical properties are largely determined by intermolecular forces, the forces of attraction and repulsion between particles. Three types of intermolecular forces are introduced below. You will examine
these forces further in Chapter 4.
• Hydrogen bonding is a strong intermolecular attraction between the hydrogen atom from an NH, OH, or FH group on one molecule, and a nitrogen, oxygen, or fluorine atom on another molecule.
• The attractive forces between polar molecules are called dipole-dipole interactions. These forces cause polar molecules to cling to each other.
• Dispersion forces are attractive forces that occur between all covalent molecules. These forces are usually very weak for small molecules, but they strengthen as the size of the molecule increases.
The process that is outlined on the next page will help you to predict the physical properties of organic compounds by examining the intermolecular forces between molecules. As you progress through the chapter, referring back to this process will enable you to understand the reasons behind trends in physical properties.
In the following ThoughtLab you will use the process in the box above to predict and compare the physical properties of some organic compounds.
Compounds With Single-Bonded Functional Groups
Alcohols, alkyl halides, ethers, and amines all have functional groups with single bonds. These compounds have many interesting uses in daily life. As you learn how to identify and name these compounds, think about how the intermolecular forces between their molecules affect their properties and uses.
Alcohols
An alcohol is an organic compound that contains the OH functional group. Depending on the position of the hydroxyl group, an alcohol can be primary, secondary, or tertiary. Figure 1.13 gives some examples of alcohols.
Table 1.6 lists some common physical properties of alcohols. As you learned earlier in this chapter, alcohols are polar molecules that experience hydrogen bonding. The physical properties of alcohols depend on these characteristics.
Additional Characteristics of Alcohols
• Alcohols are extremely flammable, and should be treated with caution.
• Most alcohols are poisonous. Methanol can cause blindness or death
when consumed. Ethanol is consumed widely in moderate quantities, but it causes impairment and/or death when consumed in excess.
Alkyl Halides
An alkyl halide (also known as a haloalkane) is an alkane in which one or more hydrogen atoms have been replaced with halogen atoms, such as F, Cl, Br, or I. The functional group of alkyl halides is RX, where X represents a halogen atom. Alkyl halides are similar in structure, polarity, and reactivity to alcohols. To name an alkyl halide, first name the parent hydrocarbon. Then use the prefix fluoro-, chloro-, bromo-, or iodo-, with a position number, to indicate the presence of a fluorine atom, chlorine atom, bromine atom, or iodine atom. The following Sample Problem shows how to name an alkyl halide.
Ethers
Suppose that you removed the H atom from the OH group of an alcohol. This would leave space for another alkyl group to attach to the oxygen atom.
The compound you have just made is called an ether. An ether is an organic compound that has two alkyl groups joined by an oxygen atom.
The general formula of an ether is ROR. You can think of alcohols and ethers as derivatives of the water molecule, as shown in Figure 1.14.
Figure 1.15 gives two examples of ethers.
To name an ether, follow the steps below. The Sample Problem then shows how to use these steps to give an ether its IUPAC name and its common name.
How to Name an Ether
IUPAC Name
Step 1 Choose the longest alkyl group as the parent alkane. Give it an alkane name.
Step 2 Treat the second alkyl group, along with the oxygen atom, as an alkoxy group attached to the parent alkane. Name it by replacing
the -yl ending of the corresponding alkyl group’s name with -oxy. Give it a position number.
Step 3 Put the prefix and suffix together: alkoxy group + parent alkane.
Common Name
Step 1 List the alkyl groups that are attached to the oxygen atom, in alphabetical order.
Step 2 Place the suffix -ether at the end of the name.
Table 1.7 describes some physical properties of ethers. Like alcohols, ethers are polar molecules. Ethers, however, cannot form hydrogen bonds with themselves. The physical properties of ethers depend on these characteristics.
Amines
An organic compound with the functional group -NH2, -NHR, or -NR2 is called an amine. The letter N refers to the nitrogen atom. The letter R refers to an alkyl group attached to the nitrogen. The general formula of an amine is R-NR′2. Amines can be thought of as derivatives of the ammonia molecule, NH3. They are classified as primary, secondary, or tertiary, depending on how many alkyl groups are attached to the nitrogen atom. Note that the meanings of “primary,” “seconday,” and “tertiary” are slightly different from their meanings for alcohols.
Figure 1.16 gives some examples of amines.
To name an amine, follow the steps below. The Sample Problem illustrates how to use these steps to name a secondary amine.
How to Name an Amine
Step 1 Identify the largest hydrocarbon group attached to the nitrogen atom
as the parent alkane.
Step 2 Replace the -e at the end of the name of the parent alkane with
the new ending -amine. Include a position number, if necessary, to
show the location of the functional group on the hydrocarbon chain.
Step 3 Name the other alkyl group(s) attached to the nitrogen atom. Instead
of position numbers, use the letter N- to locate the group(s). (If two
identical alkyl groups are attached to the nitrogen atom, use N,N-.)
This is the prefix.
Step 4 Put the name together: prefix + root + suffix.
Amines are polar compounds. Primary and secondary amines can form hydrogen bonds, but tertiary amines cannot. Table 1.8 lists some common physical properties of amines.
Additional Characteristics of Amines
• Amines are found widely in nature. They are often toxic. Many amines that are produced by plants have medicinal properties.
(See Figure 1.17.)
• Amines with low molecular masses have a distinctive fishy smell. Also, many offensive odours of decay and decomposition are caused by amines. For example, cadavarine, H2NCH2CH2CH2CH2CH2NH2, contributes to the odour of decaying flesh. This compound gets its common name from the word “cadaver,” meaning “dead body.”
• Like ammonia, amines act as weak bases. Since amines are bases, adding an acid to an amine produces a salt. This explains why vinegar and lemon juice (both acids) can be used to neutralize the fishy smell of seafood, which is caused by basic amines.
